6
Port Description
1. Audio Jack Connect headphones, headset or other devices with 3.5mm connector
2. USB-C Port Connect a USB-C device, supports 5Gb/s transfer speeds, BC 1.2 battery charging up
to 7.5W, 2.4A charging on supported Apple devices (12W)
3. USB-A Port Connect a USB-A device, supports 5Gb/s transfer speeds, BC 1.2 battery charging up
to 7.5W, 2.4A charging on supported Apple devices (12W)
4. PC1 LED PC1 LED Status Light
5. PC2 LED PC2 LED Status Light
6. Power / Switch Button Long press, (3sec) power on/off
Shot press, switch between connected hosts
7. DC Power Input Connect to power using the included power cable
8. USB-C PC2 Upstream Port Connect to a laptop or PC, supports data transfer up to 5 Gb/s, Power Pass-through
charging up to 100W
9. USB-C PC1 Upstream Port Connect to a laptop or PC, supports data transfer up to 5 Gb/s, Power Pass-through
charging up to 100W*
10. Switching Port Connect 3.5mm switch button, same function as power button
11. DP 1.4 Port Connect a display with a DP port to stream video up to 4K@60Hz
12. HDMI 2.0 Port Connect a display with an HDMI port to stream video up to 4K@60Hz
13. RJ45 Gigabit Ethernet Connect a network router or modem at 10/100/1000 Mbps
14. USB-A Port Connect a USB-A device, supports 5Gb/s transfer speeds, charging up to 4.5W
15. USB-C PD Port PC1 Connect a USB-C power supply for Power Pass-through to PC1, supports 5V/1A --
5V/20A fast charging (USB-C power adapter not included)
DOCKING STATION PORTS (Continued)
