The Data Receiver scans the pre-set Channel frequencies until acceptable data is received
for it to lock onto.
If the Data Receiver starts to receive broken data from the RF signal it is locked to, it then
starts scanning the pre-set Channel frequencies again, until acceptable data is available to
lock on to.
This process happens continually as the Data Receiver is roaming the coverage area. To
make this action appear seamless, the coverage of two or more transmissions must
overlap.
NOTE: When using more than one FCDT Transmitter unit, they must have separate
Address allocations assigned and not clash between units.
NOTE: The Head software version must be CRIF-0104-0502 or above for Scan mode to be
available.
If Scan operation is not required, it is important to set the Scan Setting option to Disable in
the Data Receiver to avoid having any affect to single frequency mode.
The Sony RCP units have an allocated Send All button. This button is used when connected
to the FocalPoint IDU. This function sends all the main Paint configuration settings from the
RCP to the camera.
The Send All operation is manually controlled by the operator using the CHARACTER
button. This operation is beneficial as it allows the operator to configure the Paint settings
alongside the Line Camera RCP units while the Wireless camera is switched off. When the
Wireless Camera is switched on, you can activate the manual Send All.
You can also configure the Send All operation to automatically send the Paint configuration
if the system is set to receive Return Data.
When the OCP Channel Return Data is set to Yes an Auto Send All option is available. This
has an adjustable timer with settings from Off to 300 Seconds or any 30 second intervals
between.
The Auto Send All operation timer starts its internal countdown when the FocalPoint
Interface Unit stops receiving Return Data (when the Wireless Camera system is turned
off). When the timer has completed its countdown, an automatic Send All (RCP Paint
settings) will be sent to the camera when the next Return Data packet is received (once the
Wireless Camera is switched on).
