User Manual Focal Point
Wireless Camera Control System
Issue No: M Page: 7
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
The FocalPoint Camera Racking system provides comprehensive control functions to meet
today’s broadcast needs. The system can control multiple camera and operator control
panel combinations with future-proof Ethernet control. The control system is designed to
work with the majority of camera manufacturers and supports one-way or return
communication. The unit supports copper or fiber optic connectivity.
The system is comprised of the four main parts:
Operators Control Panel/Remote Control Panel (OCP/RCP)
Camera Control Interface Unit (CRIU)
Camera Control Data Transmitter (FCDT)
Data Receiver (InCam-G/InCam-S/CCCU or DR07)
The basic FocalPoint Camera Racking System is capable of controlling up to six cameras by
multiplexing six control panels over a single RF link.
The system supports one-way or return data communication to the camera.
Three CRIU units can be linked together to allow control of up to 18 cameras using one RF
head.
A 2.2-inch Color LCD display with an intuitive menu system allows for easy configuration.
The front panel LEDs show data activity/system health and diagnostic information.
Compact UHF telemetry transmitter unit with copper and fiber connectivity.
The unit is configurable via the front panel or via the web browser GUI.
NOTE: The default web browser Password is ‘Gigawave’.
