Vislink L1700 User Manual

User Manual Focal Point
Camera Control Interface Unit - CRIU-ASSY-7XXX
Issue No: M Page: 14
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Mechanical Details
Unit
Dimensions
483mm (W) x 303mm (D) x 44mm (H) (19’’ x 1U High)
Weight
2.45kg. Approx.
Environmental Details
Unit
Temperature Range
- 20° C to +70° C
Operating Humidity
5 to 95% RH
Table 3-5 CRIU-ASSY-7XXX Mechanical and Environmental Specifications
Connector
7-Pin, 2-Key LEMO Socket
Pin
Signal
1
ETH_TX+
2
ETH_TX-
3
ETH_RX+
4
ETH_RX-
5
GND
6
USB_+
7
USB_-
8
+5V_OUT
Connector
3-pin XLR Plug (5-pin XLR Socket for older unit)
Pin
Signal
1
GND
2
TX+/D+
3
TX-/D-
Connector
6-Pin, 1-Key LEMO Socket
Pin
Signal
1
GND
2
RX+
3
RX-
4
TX+/D+
5
TX-/D-
6
12V Out (500mA max)
