User Manual Focal Point
Camera Control Interface Unit - CRIU-ASSY-7XXX
Issue No: M Page: 28
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
1. Set the Configuration output to Ethernet, using the following menus:
Configuration > Output: Ethernet
2. Set the Ethernet Port as required, using the following menus:
Ethernet Port > Configuration
3. Set the Ethernet Receive Port number to match the Transmitter(s) Interface Unit
Transmit Setup Port number, using the following menus:
Ethernet Port > Receive Setup > Port: XXXXX
4. Set the Destination IP and Port number as the Data Transmitter(s) Interface Unit,
using the following menus:
Ethernet Port > Transmit Setup:
Dest. IP: XXX.XXX.XXX.XXX
Port: XXX.XXX.XXX.XXX
The Unit Warning message displays No Eth Comms from Remote Unit until connection is
established.
When a controller sends data, the relevant OCP Channels Blue Tx Data indicator flashes in
both Camera Control Interface Units.
A maximum of six OCP Channels is available (this applies to a fully licensed unit).
Tally on/off control is accessible at either Camera Control Interface Unit.
Configure Tall On/Off by setting the Tally Enabled option in the OCP Channel menu. See
Section 3.4.13.3.
1. Tally Enabled: Yes
Use the Red/Green Wet/Dry 25-way D-Type connections into the Camera Control
Interface unit with the OCP input configuration.
2. Tally Enabled: No
Use the Red/Green Wet/Dry 25-way D-Type connections into the Camera Control
Interface unit with the Ethernet input configuration
NOTE: Camera Return Data is not available using this configuration.
The Grass Valley Camera and OCP require the latest software installed, with the Serial Basic
(Ser_Basic) functionality.
Set the Grass Valley OCP400 to the following required settings:
Setup Menu> OCP> Conn.Mode> Ser_Basic
Setup Menu> OCP> Ser.Level> RS-422
