User Manual Focal Point
Camera Control Data Transmitter - FCDT-ASSY-7XXX
Issue No: M Page: 33
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Connector
4-Pin XLR Plug
Pin
Signal
1
GND
2
NC
3
NC
4
+12V to +24V
Connector
3-Pin XLR Socket (5-pin XLR Plug for older unit)
Pin
Signal
1
GND
2
RX+/D+
3
RX-/D-
Connector
Optional Connectors
Pin
Signal
F1
RX
F2
TX
The Data Transmitter requires an antenna system suitable to the frequencies in use. A
Vislink Flat Plate Directional antenna may be supplied for this purpose. However, other
antennas in the appropriate frequency range are acceptable and may be used to provide
increased gain if required.
The connection between the Data Transmitter and the antenna should use a suitable
low-loss type UHF coaxial cable (RG214 or similar).
