6 MicroLinks Technology Co., Ltd.
the machine follows:
(A) Current Mode : the machine is in observing mode by
graphic of .
(B) Lamp Sign Model : there are 8 white LEDs on the
machine for lighting. For the array and corresponding
presentations of these LEDs, please refer to the following
image.
Press the button of for a long time to switch lamp
signs among 6 modes, and use the buttons of , ,
and to select.
Use to show model of manually swithcing. Press the
button of or to switch lamp sign in the mode.
Use symbol of to show automatic repetition mode.
While starting this mode, press the button or
to stop the repetition, and press it again to recover. Also,
the repetition will be stopped automatically while pressing
any other functional button, and please press button
or to restart the repetition.
For the light sources and six modes of lamp signs, please
refer to the following graphics (the full means lighting
lamp).
(B-1) Manually switching mode to light one lamp
