INSTALLATION
2 CHAPTER 2
2.3 UNPACKING
The Vitronics Soltec myReflow is packed on a wooden pallet. When necessary, the machine is
packed in crates (e.g. when shipped).
If packed in crates the following procedure (paragraph 2.3.1 and 2.3.2) should be followed.
When the machine is packed on a wooden pallet follow instructions in paragraph 2.3.2.
2.3.1 PACKET IN CRATE
FIGURE 2.2 CRATE
Use the above figure order A,B,C to uncrate. Other order can result in damaging the machine or
personal injury.
2.3.2 PACKED ON WOODEN PALLET
FIGURE 2.3 PACKING REMOVAL
C
B
A
Uncrating order:
1. Take off top cover A.
2. Remove side panels B.
3. Remove front and backcover C.
1. Remove packing material
