2.3 - UNPACKING
Installation manual myReflow
CHAPTER 2 3
FIGURE 2.4 STRAPS REMOVAL
2.3.3 LIFTING WITH FORKLIFT
When the transporting straps are removed, the myReflow can be placed on the place the cus-
tomer has provided.
FIGURE 2.5 FORKLIFT UNDER MACHINE
To lift and transport the myReflow use the positions as shown in the installation sheet at the end
of this document.
2. Remove the coverdoors at the
strap-positions (total 4).
3. Remove straps
coverdoor
strap
* = DISTANCE BETWEEN FORKS minimum 1200mm
*
