Vivax Metrotech vLoc3 Series User Manual

™
Page 10 of 59
2 vLoc3 Series Receivers
2.7.1 The Classic Screen Status Bar
All vLoc3 series screens have a status bar at the top indicating various locator settings.
0.39m
18.3
21
3 875 64
The vLoc3 Series Status Bar
1
Antenna conguration (meter response) described later
in the manual
5
Bluetooth status (If Transmitter link is tted this icon
will replace the blue tooth icon as they are mutually
exclusive)
2 Other future option 6 GPS status (see below for further explanation)
3
Signal Current/Depth to the target line. (can also be set
to display signal current on the line or both)
7 Speaker volume setting
4 Transmitter Link connection status (see section 5.5) 8 Battery type and remaining charge
2.7.2 The Classic Screen
The Classic Screen - has all the functions normally seen on a classic cable locator. The main functions being:
0.39m
18.3
17dB 116mA
SD-USA
3
2
1
4
5
6
7
8
1 Percentage of signal strength (mirrors (4) the bar graph) 5
Signal Direction forward/back arrows (only active with
Signal Direction frequencies)
2 Peak level indicator 6
360° Compass line direction indicator (turns blue when
aligned with the target line)
3 Gain setting 7
Left/Right direction to target line indicators (when in
applicable locate mode)
4
The signal strength bar graph will change color with the
level of signal distortion:
Green: Low distortion electromagnetic eld
Blue: Minor distortion in the electromagnetic eld
Red: Excessive distortion electromagnetic eld
8
Frequency selection (ashing frequency indicates
frequency selection is not valid for this screen. Choose
another frequency)
