Vivint Element CT200 Installation Guide
To Check Cool
1. From the Thermostat’s Home
screen, press and hold the
SIDE button for 3 seconds.
The Settings menu opens.
2. Highlight Installer, then press
the SIDE button. The Install
Settings menu opens.
3. Highlight Testing, then press
the SIDE button. The Testing
menu opens.
4. Highlight Cooling, then press
the SIDE button. The Cool
Test menu opens.
5. Highlight START, then
press the SIDE button. The
Thermostat screen displays
the following:
• COOL TIME: how long the
test has been running in
minutes and seconds
• ACTIVE: the wires the
system is using to com-
municate with the cooling
system (example: Y, G)
• CHANGE: the amount
of temperature change
caused during the test
(example: -2.6°)
6. Wait for the test to end, or
highlight the back arrow
and press the SIDE button.
A test of a successfully
functioning cooling system
will show a drop in the
temperature, as well as the
proper wires indicated as
being active. If the temperature
appears to rise, or the wrong
wires are indicated as being
active, the test indicates a
problem with the Thermostat
installation. Check the wire
connections and run the cooling
test again.
COOL TEST
STOP
COOL TIME: 19:59
ACTIVE: Y, G
CHANGE: -2.6°
21
