DLP Projector—User’s Manual
3.
Remove the three screws
from the lamp module.
4.
Lift the module handle up.
5.
Pull firmly on the module
handle to remove the lamp
module.
6.
Reverse steps 1 to 5 to install
the new lamp module.
While installing, align the
lamp module with the
connector and ensure it is
level to avoid damage.
Note: The lamp module must
sit securely in place and the
lamp connector must be con-
nected properly before
tightening the screws.
