44
Projection distance and size
Projection distance and size specification
Image diagonal
(cm/inch)
Image width (cm/inch) Image width (cm/inch) Projection distance
(cm/inch)
76.2/30 66.4/26.14 37.4/14.72 112.5/44.29
101.6/40 88.6/34.88 49.8/19.61 150.3/59.17
114.3/45 99.6/39.21 56/22.05 169.1/66.57
127/50 110.7/43.58 62.3/24.53 188/74.02
152.4/60 132.8/52.28 74.7/29.41 225.8/88.9
177.8/70 155/61.02 87.2/34.33 263.6/103.78
203.2/80 177.1/69.72 99.6/39.21 301.2/118.58
228.6/90 199.2/78.43 112.1/4.13 339.1/133.5
Note:
Due to the differences in optical components, around 10% tolerance may exist in such offset
tables.
