3
176lbs
(79.8 kg)
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
ASSEMBLY STEPS
STEP 1
Loosen the two set screws on the telescopic crossbar (A) using the Allen wrench (S-F). Adjust the
crossbar length to suit the desktop. Retighten all screws.
TOOLS NEEDED
Phillips
Screwdriver
STEP 2
Place the crossbar spacer (D) on the motorized leg (B) as shown. Attach the
telescopic crossbar to the legs (B, C) as shown using M6x12mm bolts (S-A),
and tighten with the Allen wrench (S-F).
Drill
NOTE: Insert all necessary
screws into holes before
tightening.
Level
To Next Page
