Vivo MOUNT-E-FD70 - Assembly Preparation; Tools and Package Contents

4
PACKAGE CONTENTS
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED
M-G (x8)
Small Spacer
M-E (x4)
M8x50mm Screw
M-A (x4)
M5x14mm Screw
M-B (x4)
M6x14mm Screw
M-C (x4)
M6x30mm Screw
M-F (x4)
Square Washer
M-D (x4)
M8x30mm Screw
Please consult the parts list below and ensure you have everything you need to assemble
your product. If parts are missing or damaged, please contact us.
Phillips Screwdriver
|
TOOLS NEEDED:
A (x1)
Mount
B (x1)
Center Plate
C (x1)
Celing Template
H (x1)
Remote
D (x2)
Decorative Cover
E (x2)
VESA Bracket
F (x2)
Bracket Rail
G (x1)
AC Adapter
DIFFICULTY LEVEL
Drill Pencil
M-H (x8)
Large Spacer
W-A (x6)
ST6.3x55mm
Screw
W-B (x6)
Concrete Anchor
W-C (x4)
Washer
I (x4)
Cable Tie
J (x2)
Leveling Knob
T-A (x1)
3mm Allen Wrench
S-A (x4)
Set Screw
S-B (x4)
M6x25mm Screw
S-C (x4)
M6 Washer
S-D (x4)
M6 Nut
S-E (x4)
M4x8mm Screw
