Vivotek FD8156 - Page 174

VIVOTEK
174 - User's Manual
54
weekday 0~127 127 6/6 Indicate which weekday is
scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on
Friday and Sunday, set weekday as
66.
begintime hh:mm 00:00 6/6 Start time of the weekly schedule.
endtime hh:mm 24:00 6/6 End time of the weekly schedule.
(00:00~24:00 indicates schedule
always on)
prefix string[16] NULL 6/6 Indicate the prefix of the filename.
cyclesize 100~ 100 6/6 The maximum size for cycle
recording in Kbytes when choosing
to limit recording size.
reserveamount 0~15000000 100 6/6 The reserved amount in Mbytes
when choosing cyclic recording
mechanism.
dest cf,
0~4
cf 6/6 The destination to store the
recorded data.
“cf” means local storage (CF or SD
card).
“0” means the index of the network
storage.
cffolder string[128] NULL 6/6 Folder name.
trigger schedule,
networkfail
schedule 6/6 The event trigger type
schedule: The event is triggered by
schedule
networkfail: The event is triggered
by the failure of network
connection.
