VIVOTEK
User's Manual - 7
DI/DO Diagram
Please refer to the following illustration for the connection method.
NOTE:
The maximum output load from pins #7 & 8 is 50mA.
Gnd
Camera Power
Input
Output
5
8
6
7
+12
VDC
Max.
VDC
Switch
BJT transistor
Gnd
Camera Power
Input
Output
5
8
6
7
+12
VDC
VDC
Switch
BJT transistor
Relay
Relay
12V
+12V
Digital output
PIN 8
Power+12V
PIN 7
Digital input
PIN 6
Ground
PIN 5
