Vivotek FD8163 User Manual

VIVOTEK
User's Manual - 9
IMPORTANT!
Before installing your camera, make sure the built-in PIR (Passive Infrared Sensor) can be
directed toward the area of interest, where intrusions may occur. (The sensitivity of PIR
sensor depends on the object size and temperature differences between the object and the
background environment.)
Installation
Removing Dome Cover
Use the included T10 Torx screwdriver to loosen screws on the sides of dome cover to
remove it. You should then jot down the MAC address printed on the bottom of the camera.
50
50
5m
41
41
5m
FD8163
Dome Cover
Bottom of the Camera

Vivotek FD8163 Specifications

General

Brand	Vivotek
Model	FD8163
Category	Security Camera
Language	English
