VIVOTEK
78 - User's Manual
WDR enhanced: This function allows users to identify more details of objects in the high contrast
environment especially for details in the shaded area. You may check the Enable WDR checkbox,
and then adjust the sensitivity (low, high) and the strength (low, medium, high) to reach the best
image quality.
Exposure
Advanced Mode
On this page, you can set the Measurement window, Exposure level, Exposure mode, Iris
adjustment, Iris speed, Exposure time, and Gain control settings. Detailed congurations will be
automatically adjusted since the sensor library will automatically adjust the value according to the
ambient light.
Sensor Setting 1:
For normal situations
You can click Restore to recall the original settings without incorporating the changes. When
completed with the settings on this page, click Save to enable the setting. You can also click on
Prole to adjust all settings above in a pop-up window for special lighting conditions.
Activated period: Select the mode this profile to apply to: Day mode, Night mode, or Schedule
mode. Please manually enter a range of time if you choose Schedule mode. Then check Save to
take effect.
Sensor Setting 2:
For special situations
