VIVOTEK
User's Manual - 27
Ready to Use
1� A browser session with the Network Camera should prompt as shown below�
2� You should be able to see live video from your camera� You may also install the 32-channel
recording software from the software CD in a deployment consisting of multiple cameras� For
its installation details, please refer to its related documents�
To adjust the viewing angle -- 3-axis mechanism design
1� Loosen the tilt adjustment screws and then turn the lens module up or down, or swing left or
right� Upon completion, tighten the screw�
2� Turn the lens to adjust the image orientation�
Horizontal Pan 350°
Lens Horizontal Pan
350°
Vertical Tilt 65°
1
2
Tilt Adjustment Screws
To Next Page
