VIVOTEK
User's Manual - 85
Network > Streaming protocols
HTTP streaming
To utilize HTTP authentication, make sure that your have set a password for the Network Camera
rst; please refer to Security > User account on page 95 for details.
Authentication: Depending on your network security requirements, the Network Camera provides
two types of security settings for an HTTP transaction: basic and digest.
If basic authentication is selected, the password is sent in plain text format and there can be
potential risks of being intercepted� If digest authentication is selected, user credentials are
encrypted using MD5 algorithm and thus provide better protection against unauthorized accesses�
HTTP port / Secondary HTTP port: By default, the HTTP port is set to 80 and the secondary HTTP
port is set to 8080� They can also be assigned to another port number between 1025 and 65535� If
the ports are incorrectly assigned, the following warning messages will be displayed:
To access the Network Camera on the LAN, both the HTTP port and secondary HTTP port can
be used to access the Network Camera� For example, when the HTTP port is set to 80 and the
secondary HTTP port is set to 8080, refer to the list below for the Network Camera’s IP address�
Access name for stream 1 ~ 3: This Network camera supports multiple streams simultaneously�
The access name is used to differentiate the streaming source� Users can click Media > Video >
Stream settings
to set up the video quality of linked streams� For more information about how to
set up the video quality, please refer to Stream settings on page 67�
When using Mozilla Firefox or Netscape to access the Network Camera and the video mode is
set to JPEG, users will receive video comprised of continuous JPEG images� This technology,
known as “server push”, allows the Network Camera to feed live pictures to Mozilla Firefox and
Netscape�
On the LAN
http://192.168.4.160 or
http://192.168.4.160:8080
