EN - 11
English
For further setup, please
refer to the user's
manual on the software
CD.
Ready to Use
6
1. A browser session with the Network Camera should prompt as shown below.
2. You should be able to see live video from your camera. You may also install the 32-channel recording
software from the software CD in a deployment consisting of multiple cameras. For its installation
details, please refer to its related documents.
Based on the live image retrieved from the camera, adjust the camera lens by doing the following:
To adjust the viewing angle -- 3-axis mechanism design
1. Loosen the tilt adjustment screws and then turn the lens module up or down. Upon completion,
tighten the screw.
2. Turn the lens to adjust the image orientation.
1
2
Adjusting the Lens
7
Horizontal Pan
350°
Lens Horizontal
Pan 350°
Vertical Tilt 80°
Tilt Adjustment
Screws
To Next Page
