Vivotek FD8335H Quick Installation Guide

EN - 3
English
IR LEDs (18 units, effective up
to 15m)
Physical Description
2
Inner View
Lens
Tilt Adjustment Screw
Black Cover
1. There is no internal microphone. Only external microphone is applicable.
2. The Focus Assist button takes effect when using a hand-held monitor or camera
tester with a BNC connector. Press the button and use the focus and zoom
adjustment pullers to tune the image until the "BEST FOCUS" message is
shown.
Ethernet 10/100
RJ45 Socket
Audio/Video
Out (green)
Microphone In
(pink)
General I/O Terminal
Block
Jumpers
Microphone
Video Output
Internal
External
NTSC
60Hz
PAL
50Hz
1
2
Micro SD/SDHC Card Slot
Reset
Button
Focus Assist Button
LCD Monitor/
Camera tester
AV Out
Focus Assist
Button
