VIVOTEK
User's Manual - 9
4. Attach the alignment sticker to a preferred location, and drill mounting holes. Hammer in
the plastic anchors.
3. When selecting an installation position, note the PIR detection range as illustrated below.
77.3°
121°
5M
5M
