Vivotek FE8171V - Motion Detection Settings

VIVOTEK
User's Manual - 151
<product dependent> pcma
7.15 Time Shift settings
Group: timeshift, c for n channel products, m is stream number (capability.timeshift > 0)
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
enable <boolean> 0 4/4 Enable time shift streaming.
c<0~(n-1)>_s<0~
(m-1)>_allow
<boolean> 0 4/4 Enable time shift streaming for
specific stream.
7.16 Motion detection settings
Group: motion_c<0~(n-1)> for n channel product
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
enable <boolean> 0 4/4 Enable motion detection.
win_i<0~4>_enable <boolean> 0 4/4 Enable motion window 1~3.
win_i<0~4>_name string[14] <blank> 4/4 Name of motion window 1~3.
win_i<0~4>_polygon 0 ~ 320,0 ~
240, 0 ~
320,0 ~
240, 0 ~
320,0 ~
240, 0 ~
320,0 ~ 240
0 4/4 Coordinate of polygon window
position.
(4 points:
x0,y0,x1,y1,x2,y2,x3,y3)
win_i<0~4>_objsize 0 ~ 100 0 4/4 Percent of motion detection
window.
win_i<0~4>_sensitivity 0 ~ 100 0 4/4 Sensitivity of motion detection
window.
Group: motion_c<0~(n-1)> profile for m profile and n channel product (capability.nmotionprofile > 0)
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
i<0~(m-1)>_enable <boolean> 0 4/4 Enable profile 1 ~ (m-1).
i<0~(m-1)>_policy day,
night,
schedule
night 4/4 The mode which the
profile is applied to.
i<0~(m-1)>_begintime hh:mm 18:00 4/4 Begin time of schedule
