Vivotek FE8174 User Manual

VIVOTEK
12 - User's Manual
You may also install the camera to a U.S. standard 4 in. junction
box. You can align the camera’s curved slots with the mounting
holes on a junction box. Use diagonal mounting positions on the
camera to match those on a junction box.
Install the plastic dome cover by aligning the snap-
t tabs on the dome cover with the slotted tabs on the
camera base. Install the dome cover by pressing it even-
ly to the camera base.
Make sure the dome cover and the base plate are ush-
aligned before pressing down. The dome cover is se-
cured using a snap-t mechanism.
NOTE:
Attach the Dome Cover
Snap-t tabs
Slotted tabs
Dome cover

Vivotek FE8174 Specifications

General

Type	IP security camera
PTZ control	Yes
Placement supported	Indoor
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Signal-to-Noise Ratio (SNR)	62 dB
Form factor	Dome
Mounting type	Ceiling
Product color	White
Maximum resolution	2560 x 1920 pixels
Supported video modes	-
Video formats supported	H.264, MPEG4
Power source type	PoE
Minimum illumination	0.03 lx
Sensor type	CMOS
Digital zoom	12 x
Built-in HDD	No
Flash memory	128 MB
Internal memory	256 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC

Weight and Dimensions

Length	34 mm
Weight	358 g
Diameter	139 mm
