Vivotek FE8174 - Privacy Mask

VIVOTEK
User's Manual - 173
theme_color_font string[7] #ffffff 1/6 Font color
theme_color_configfont string[7] #ffffff 1/6 Font color of configuration area.
theme_color_titlefont string[7] #098bd6 1/6 Font color of video title.
theme_color_controlbackgroun
d
string[7] #565656 1/6 Background color of control
area.
theme_color_configbackground string[7] #323232 1/6 Background color of
configuration area.
theme_color_videobackground string[7] #565656 1/6 Background color of video area.
theme_color_case string[7] #323232 1/6 Frame color
7.27 Privacy mask
Group: privacymask_c<0~(n-1)> for n channel product
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
enable <boolean> 0 4/4 Enable privacy mask.
win_i<0~4>_enable <boolean> 0 4/4 Enable privacy mask
window.
win_i<0~4>_name string[14] <blank> 4/4 Name of the privacy mask
window.
win_i<0~4>_
polygon
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240
0 4/4 Coordinate of polygon
window position.
(4 points:
x0,y0,x1,y1,x2,y2,x3,y3)
7.28 Capability
Group: capability
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
api_httpversion <string> 0100a 0/7 The HTTP API version.
bootuptime <positive integer> 60 0/7 Server bootup time.
nir 0,
<positive integer>
0 0/7 Number of IR interfaces.
(Recommand to use ir for built-in
IR and extir for external IR)
npir 0,
<positive integer>
0 0/7 Number of PIRs.
