D. Technical specifications
- System
CPU: Vivotek VVTK-1000
RAM: 32MB SDRAM
ROM: 4MB FLASH ROM
Image Sensor: VGA CMOS
Embedded OS: Linux2.4
- Networking
Protocols
TCP/IP, HTTP, SMTP, FTP, DDNS, UPnP, Telnet, NTP, DNS, DHCP
and RTSP
Physical
10/100 baseT Fast Ethernet auto negotiation
- Video
Algorithm supported
MPEG4(simple profile) for streaming video
JPEG for still image
Features
Adjustable image size, quality and bit rate
Time stamp and text overlay
3 motion detection windows
Resolution
Up to 30/25 frames at 160x120
Up to 30/25 frames at 320x240
Up to 30/25 frames at 640x480
- Camera Specification
1/4 inch color CMOS sensor
Resolution: 640x480
1.5Lux/F2.0
AGC, AWB, AES
Electronic shutter: 1/60 ~ 1/15000 second
- Lens
Fixed focal with fine tuning, 4.0mm, F2.0
- Stream
MPEG-4 streaming over UDP, TCP, ir HTTP
MPEG-4 multicast streaming
- Event Management
Multiple-window video motion detection
1 digital input and 1 digital output
Event notification using HTTP, SMTP, of FTP
- Audio
Supports GSM-AMR
Supports AAC compression
Supports audio mute
Bit rate:
GSM-AMR: 4.75k~12.2k
ACC: 15k~128k
- Security
Multi-level user access
IP address filtering
- LED indicator
Bi-color LED system status indicator
- Dimension
126.4mm (L) x 96.2mm (W) x 47.4mm (H)
- Weight
NET. 276g
- Power
12V DC
Power over Ethernet: 802.3af compliant
- Operating Environment
Temperature: 0-40°C/32-104°F
Humidity: 20%~80% RH
- EMI & Safety
CE, FCC, PSE
- Application
Installation wizard
16-ch recording software
SDK available for application development and system
integration
- Viewing system requirement
OS: Microsoft Windows 2000/XP
Browser: Internet Explorer 5.x or above
Cellphone: 3GPP player
Real Player 10.5
Quick Time 6.5
Packet Video Player 3.0
