VIVOTEK
138 - User's Manual
5.22 UART Control
Group: uart (capability.nuart>0) (product dependent)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
ptzdrivers_i<0~19, 127>_name string[40] 1/4 Name of the PTZ driver.
ptzdrivers_i<0~19, 127>_location string[128] 1/4 Full path of the PTZ driver.
enablehttptunnel <boolean> 4/4 Enable HTTP tunnel channel to control
UART.
Group: uart_i<0~(n-1)> n is uart port count (capability.nuart>0)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
baudrate 110,300,600,1200,2400,36
00,4800,7200,9600,19200,
38400,57600,115200
4/4 Set baud rate of COM port.
databit 5,6,7,8 4/4 Data bits in a character frame.
paritybit none, odd, even 4/4 For error checking.
stopbit 1,2 4/4 1
2-1.5 , data bit is 5
2-2
uartmode rs485, rs232 4/4 RS485 or RS232.
customdrvcmd_i<0~9> string[128] 1/4 PTZ command for custom
camera.
speedlink_i<0~4>_name string[40] 1/4 Additional PTZ command name.
speedlink_i<0~4>_cmd string[128] 1/4 Additional PTZ command list.
ptzdriver 0~19, 127 (custom),
128 (no driver)
4/4 The PTZ driver is used by this
COM port.
5.23 SNMP
Group: snmp (capability.snmp) (product dependent)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
v2 0~1 6/6 SNMP v2 enabled. 0 for disable, 1 for enable
v3 0~1 6/6 SNMP v3 enabled. 0 for disable, 1 for enable
secnamerw string[31] 6/6 Read/write security name
secnamero string[31] 6/6 Read only security name
authpwrw string[8~128] 6/6 Read/write authentication password
