VIVOTEK
User's Manual - 141
Bit 7 => External or built-in PT; (built-in),
1(external)
Bit 8 => Invalidate bit 1 ~ 7; 0(bit 1 ~ 7 are
valid), 1(bit 1 ~ 7 are invalid)
Bit 9 => Reserved bit; Invalidate lens_pan,
Lens_tilt, lens_zoon, lens_focus, len_iris.
0(fields are valid),
1(fields are invalid)
eptz <positive integer> 0/7 A 32-bit integer, each bit can be set
separately as follows:
Bit 0 => stream 1 supports ePTZ or not.
Bit 1 => stream 2 supports ePTZ or not.
The rest may be deduced by analogy
npreset <positive integer> 0/7 Number of preset locations.
protocol_https < boolean > 0/7 Indicate whether to support HTTP over SSL.
protocol_rtsp < boolean > 0/7 Indicate whether to support RTSP.
protocol_sip <boolean> 0/7 Indicate whether to support SIP.
protocol_maxconnecti
on
<positive integer> 0/7 The maximum allowed simultaneous
connections.
protocol_rtp_multicas
t_scalable
<boolean> 0/7 Indicate whether to support scalable
multicast.
protocol_rtp_multicas
t_backchannel
<boolean> 0/7 Indicate whether to support backchannel
multicast.
protocol_rtp_tcp <boolean> 0/7 Indicate whether to support RTP over TCP.
protocol_rtp_http <boolean> 0/7 Indicate whether to support RTP over HTTP.
protocol_spush_mjpe
g
<boolean> 0/7 Indicate whether to support server push
MJPEG.
protocol_snmp <boolean> 0/7 Indicate whether to support SNMP.
protocol_ipv6 <boolean> 0/7 Indicate whether to support IPv6.
videoin_type 0, 1, 2 0/7 0 => Interlaced CCD
1 => Progressive CCD
2 => CMOS
videoin_resolution <a list of available
resolution separated
by commas>
0/7 Available resolutions list.
videoin_maxframerat
e
<a list of available
maximum frame rate
separated by
commas>
0/7 Available maximum frame list.
