VIVOTEK
User's Manual - 11
The Network Camera is PoE-compliant, allowing transmission of power and data via a single
Ethernet cable. Follow the below illustration to connect the Network Camera to a PoE-enabled
switch via Ethernet cable�
Use a PoE power injector (optional) to connect between the Network Camera and a non-PoE
switch�
Network Deployment
When using a PoE-enabled switch
RJ45 Female/
Female Coupler
When using a non-PoE switch
POWER
COLLISION
LINK
RECEIVE
PARTITION
1
2
3
4
5
PoE Switch
POWER
COLLISION
LINK
RECEIVE
PARTITION
1
2
3
4
5
PoE Power
Injector
(Optional)
Non-PoE Switch
