Physical description
Front panel
Connectors
General I/O Terminal Block
This Network Camera provides a general I/O terminal block which is used to connect external
input / output devices. The pin definitions are described below.
Status LED
P
Privacy button
Lens
Built-in Microphone
ETHERNET
RESET
IO
1234
General I/O
terminal block
Indented reset button
Power cord socket
Ethernet 10/100
RJ45 socket
1: Power
2: Digital output
3: Digital input
4: Ground
