Vivotek SD8362E - Physical Description

VIVOTEK
6 - User's Manual
Physical Description
Reset Button
Lens
Status LEDs
SD Card Slot
GND
DO2-
DO1-
DO+
GND
D13
D12
D11
GND
DO2-
DO1-
DO+
GND
D13
D12
D11
Ethernet 10/100 RJ45
Plug
Audio Out (green)
Microphone In (pink)
Power Cord Socket
(black)
General I/O Terminal
Block
Ground
