viZaar VUMAN E3 - 2 Specifications - Technical Data; VUMAN E3;E3+ -Specifications

10 11
SAFETY INSTRUCTIONS
2.1 VUMAN E3/E3+ - SPECIFICATONS*
SPECIFICATIONS - TECHNICAL DATA
Dimensions in mm / inch (W) 335 / 13.19” x (H) 410 / 16.14” x (D) 275 / 10.83”
Weight 8.5 kg / 18.7 lbs (10 kg / 22 lbs X-WAY)
Environmental Specications
Operation temperature 5°F to +118°F (-15°C to +48°C)
Storage temperature -13°F to +150°F (-25° to +65°C)
Relative humidity max. 95%, non condensing
AC input 100-240 VAC. 50/60 Hz, 750 mA
Construction Aluminum – carbon bre with elastomer bumpers
X-WAY drive Integrated compressor, maintenance free*
Video input Composite and S-Video
Video output HDMI, Composite and S-Video*
Connectors and outlets
USB 3.0 | 12VDC / 750mA Aux-Out | Optional external compressed air |
Rechargeable battery
LED dual light source
Lifetime guarantee | High eciency dual LED illumination |
Color temperature: 6.500 K (daylight quality)
System memory
ca. 80GB: up to several hours of high resolution AVI video-recording or
several thousand JPG high quality images.
Probe and camera material
Polyurethane, polyolen, VA-steel, tungsten, viton, epoxy resin, acrylic,
glass
BASE UNIT
VUSCREEN CONTROL PANEL
Dimensions in mm / inch (W) 320 / 12.6” x (H) 30 / 1.18” x (D) 230 / 9.06”
Weight 1.6 kg /3.5 lbs
Mounting Base Unit: clamp secured storage | Portable: shoulder strap
TFT display
Size: 10.4“ | Contrast 700:1 | Brightness: 700 cd/m² | Backlight: LED,
transreective | Colors: True Color | Viewing angle: +/-80° in all
directions
Operation
Resistive touch screen incl. ve direct access buttons and joystick
(approved for operation with working gloves)
Construction
Carbon bre design with all around elastomer bumper;
power cable 2.5 meter (8.2 ft)
* Changes in the specications can occur and will be edited without giving notice. Please contact the manufacturer for further
information.
**only in some VUMAN E3/E3+ versions
