STRUCTURE - START-UP
3.3 SETUP
1. Release control unit (lift latch)
1
2. Connect the umbilical cable to the base unit.
2
3. Connect the umbilical cable to the VUSCREEN
control unit.
3
3.3.1 POSSIBLE OPTIONS TO USE THE VUSCREEN UNIT
A
A ON THE WORKBENCH
Put the panel down onto a clean workbench.
B
B ON THE SYSTEM
Return the control unit back into the bracket with the
display showing outside and lock it by pushing the
latch down.
