viZaar VUMAN E3 - Removal from the Transport Case

16 17
STRUCTURE - START-UP STRUCTURE - START-UP
3.2 REMOVAL FROM THE TRANSPORT CASE
OTHER*
Check the transportcase for possible
transport damage before opening it.
Dimensions (H) 640 x (B) 645 x (T) 455 mm
Weight (empty) 8,7 kg
1
Pull-out handle for ease of transprtation
2
Pull in handle
3
Wheels
4
Press the button to unlock the lever
A
Lift here to open the transport case
B
3 Toggle locks
Lock
Unlock
1
4
2
3
B
A
1. LCD display protective foil.
*optional accessories, not included
