SYMPTOMS PROBABLE CAUSE CORRECTIVE ACTION
During unloading phase,
pressure increases up to safety
valve opening
1-The intake valve remains open. 1-Check the valve. If necessary, replace the damaged parts with the spare parts kit.
2-The calibrated nozzle is clogged. 2-Remove the calibrated nozzle. Clean or replace it.
Oil leakage from intake valve
only when the machine is
switched off: oil soaked-up air
filter
1-The intake valve does not work properly
(does not close)
1-Check the valve. If necessary, replace the damaged parts with K9 spare parts kit.
2-The non-return valve of intake valve does not work
correctly.
2-Check it and clean it.
Oil soaked-up air filter during
unloading phase
1-Too high level of oil in the tank 1-Check oil level on separator tank (see the chapter 6).
2- Clogged separator filter 2- Replace the separator filter.
3-The recovery oil viewer is dirty or does not work
appropriately.
3 -Clean it or if necessary, replace the damaged parts with the K15 spare parts kit.
If separator filter is clogged up, replace it.
The compressor remains under
loading phase.
1-The intake valve does not work properly
(does not close)
1-Check the valve. If necessary, replace the damaged parts with the spare parts kit.
Rotor seizure
1-Unknown particles inside. 1-Call VMC technical support.
2-Insufficient lubrication. 2-Call VMC technical support.
Presence of oil in the outlet of
minimun pressure valve
1-Separator filter damaged. 1-Replace the separator filter.
2-Oil recovery viewer obstructed. 2-Clean the oil recovery viewer.
3-Separator nipple with o-rings damaged.
3-Replace K1 spare parts kit.
