Vogt MD Series User Manual

33
Maintenance
Maintenance
7.12 Recommended Tightening Torques for Assembly
25.01
25.02
25.03
25.04
25.23
25.25
26.01
26.08
28.01
Union Body Bolt/Pump Body
Union Body Bolt/Body Bearing
Suction Side Bearing Body Cover Bolt
Leg Fixing Bolt Bearing Body
Bearing Housing-Bearing Body Bolt
Bearing Body Housing Cover Fixing Bolt
Stud Seal Holder Box
Pump cover fastening stud - Union body
Shaft Nut
Item.
Denomination
Figure 27
25.01
Item.
Nominal Size
Torque Tightening
Newton-meter
5/16
3/8
7/16
1/2
5/8
7/16
1/2
5/8
1/4
3/8
7/16
1/4
3/8
7/16
1/4
5/16
3/8
7/16
1/4
5/16
5/16
3/8
7/16
1/4
5/16
3/8
5/16
3/8
1/2
5/8
3/4
1
25.02
25.03
25.04
25.23
25.25
26.01
26.08
28.01
21
36
59
85
167
59
85
167
10
36
59
10
36
59
10
21
36
59
10
21
21
36
59
19
21
36
21
36
85
167
279
637
