Void Cyclone 55 - Bias D1;Q1;Q2 Phoenix Wiring; Bias Q3;Q5 Speakon Wiring

Page 13UG10583-2.0 - Cyclone 55 User Guide V2.0
4.6 Bias D1/Q1/Q2 Phoenix wiring
Figure 4.8: Bias D1 output connection Figure 4.9: Bias Q1/Q2 output connection
Bias D1/Q1/Q2 Out 1
Output LF (2 x 5”) and HF (2 x 1”)
Max parallel units 4 (2 Ω load to amplifier)
1+
1-
+
-
Figure 4.11: Bias Q5
Bias Q3/Q5 Out 1
Output LF (2 x 5”) and HF (2 x 1”)
Max quantity per channel 4 (2 Ω load to amplifier)
4.5 Bias Q3/Q5 speakON
TM
wiring
1-
1+
1+
1-
1-
1+
1+
1-
1+
1-
+
-
Figure 4.10: Bias Q3
