Void Cyclone 55 - Cyclone 55 Specifications

Page 7UG10583-2.0 - Cyclone 55 User Guide V2.0
3 About
3.4 Cyclone 55 specifications
Frequency response 70 Hz - 23 kHz ±3 dB
Eciency
1
92 dB 1W/1m
Nominal impedance 16 Ω
Power handling
2
120 W AES
Maximum output
3
110 dB cont, 114 dB peak
Driver configuration 2 x 5” LF, 2 x 1” soft dome HF tweeters
Dispersion 110°H x 70°V
Connectors Phoenix connectors with link out
Height 192 mm (7.6”)
Width 309 mm (12.2”)
Depth 207 mm (8.1”)
Weight 3.2 kg (7.1 lbs)
Enclosure Fibreglass
IP Rating IP-55 (BS EN 60529:1992 +A2:2013)
Rigging Wall bracket included, type 51 plate
Finish Smooth cellulose
1
Measured in half space
2
AES2 - 1984 compliant
3
Calculated
Figure 3.1: Horizontal directivity isobars Figure 3.2: Vertical directivity isobars
