– Unscrew wiring retainer -arrow- from alternator -C- .
– Remove alternator -C- .
Installing
Install in the reverse order of removal. When doing this, note the
following:
Caution
♦ In order to avoid damage to cylinder block, note the dif‐
ferent bolt lengths for aluminium and grey cast iron cylin‐
der blocks when installing the ancillary bracket. ⇒ Engine;
Rep. gr. 13 .
♦ When installing used poly V-belts observe the direction of
rotation marked on removal!
♦ Before installing poly V-belt, make sure all assemblies
( alternator -C- / air conditioner compressor) are firmly in
position.
♦ When fitting belt, ensure that poly V-belt seats correctly in
pulleys!
– Drive threaded sleeves -A- roughly 4 mm in
-direction of arrow- out of alternator -C- housing.
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
7. Alternator C 93
