9.4 Tail light in side panel (LED) - saloon
1 - Nut
❑ 3.5 Nm
2 - Tail light in side panel
❑ Removing and installing
⇒ page 309
9.5 Removing and installing tail light in side
panel (LED) - saloon
The tail light in the side panel with LED cannot be dismantled
further. It comprises the following components:
♦ Left tail light bulb -M4- / right tail light bulb -M2-
♦ Left brake and tail light bulb -M21- / right brake and tail light
bulb -M22-
♦ Rear left turn signal bulb -M6- / rear right turn signal bulb -M8-
Caution
♦ Switch off ignition and all electrical consumers.
♦ Remove the ignition key.
Removing
– Push side panel trim to the side.
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
9. Tail lights 309
