7.4 Alternator -C- 1.4l petrol engine
7.4.1 Assembly overview
1 - Hexagon head flange bolt
60 Nm
2 - Washer
3 - Tensioning roller
4 - Hexagon head flange bolts
20 Nm
5 - Hexagon head flange bolts
40 Nm
6 - Ancillary bracket
For alternator -C- and
air conditioner compres‐
sor
Tightening sequence ⇒
Engine; Rep. gr. 13
7 - Hexagon head flange bolt
20 Nm
8 - Hexagon head flange bolts
40 Nm
9 - Protective cap
10 - Hexagon bolts with wash‐
er
2 Nm
11 - Protective cap for carbon
brushes
12 - Voltage regulator -C1-
Removing and installing ⇒ page 168
13 - Alternator -C-
Removing and installing ⇒ page 91
Checking ⇒ page 89
Securing battery positive wire ⇒ page 88
Removing and installing poly V-belt pulley ⇒ page 163
14 - Poly V-belt
Checking ⇒ page 88
Process ⇒ power unit; Rep. gr. 13
Removing and installing ⇒ Engine; Rep. gr. 13
15 - Hexagon bolt with washer and threaded element
2 Nm
16 - Poly V-belt tensioning element
Not illustrated
Nut of B+ wire on rear of alternator: 15 Nm
Nut of wire holder on back of alternator : 3.2 Nm
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
90 Rep. gr.27 - Starter, current supply, CCS
