– Remove both bolts -arrows- for headlight range control unit .
– Lift dipped beam reflector in headlight slightly and turn the left
headlight range control motor -V48- so that the ball head -1-
can be slid out of the ball head mounting -2- in
-direction of arrow-.
– Lower the reflector in the headlight again, lift the left headlight
range control motor -V48- -1- slightly and turn it in
-direction of arrow-.
– Take the left headlight range control motor -V48- out of the
headlight housing as far as the connected wiring allows.
– Disconnect connection -2- and remove left headlight range
control motor -V48- -1-.
Installing
Carry out installation in the reverse sequence, noting the follow‐
ing:
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
270 Rep. gr.94 - Lights, bulbs, switches - exterior
