11 Additional brake lights
11.1 Removing and installing additional
brake light bulb -M25- - saloon
Note
♦ Failure of LEDs in additional brake lights:
♦ The individual LEDs in the additional brake lights are com‐
prised in groups of four LEDs and are supplied with current in
groups.
♦ The additional brake light is designed in such a way that the
legal requirements are still met in the event that one LED group
fails.
♦ If a further LED group fails, these requirements are no longer
met according to the legislator.
♦ Due to the failure of one LED group, the intact LEDs are placed
under increased strain; it must be anticipated that further LED
groups will soon fail.
♦ If more than four individual LEDs in the additional brake light
have failed, the additional brake light must be renewed (repair
measure).
Caution
♦ Switch off ignition and all electrical consumers.
♦ Remove the ignition key.
Removing
– Remove strip roof leading edge ⇒ General body repairs, in‐
terior; Rep. gr. 70 .
– Disconnect connector -1-.
– Push high-level brake light bulb -M25- -in direction of arrow-
to rear window.
Installing
Carry out installation in the reverse sequence, noting the follow‐
ing:
– When installing additional brake light bulb -M25- , ensure the
seal is seated correctly.
11.2 Removing and installing additional
brake light bulb -M25- - estate
The additional brake light bulb -M25- is located in the roof spoiler
over the rear window.
The illumination of high-level brake light bulb -M25- is provided
by LEDs.
The additional brake light bulb -M25- cannot be dismantled.
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
316 Rep. gr.94 - Lights, bulbs, switches - exterior
