3.5 Assembly overview - oil pump, sump, balancer shaft module with spur gear
drive
1 - Oil sump
❑ Removing and installing
⇒ page 117 .
❑ With oil level and oil
temperature sender -
G266- ⇒ page 106 .
❑ If an oil level sender is
not installed, use seal‐
ing cap ⇒ ETKA (elec‐
tronic parts catalogue) .
2 - 15 Nm
3 - Intake connecting pipe
❑ Clean strainer if soiled.
4 - 10 Nm
5 - O-ring
❑ Renew.
6 - Oil pump
❑ Removing and installing
⇒ page 107 .
❑ Before installing, check
that the two dowel
sleeves for centring oil
pump on balancer shaft
module are fitted.
7 - Drive shaft for oil pump
8 - Circlip
❑ Must lie in base of
groove.
❑ Renew damaged or
over-tensioned circlip.
9 - Spur gear for balancer shaft
10 - 20 Nm + 90° (
1
/
4
turn) further
❑ Renew.
11 - Hub
❑ For intermediate gear wheel.
❑ Renew.
12 - 90 Nm + 90° (
1
/
4
turn) further
❑ Renew.
13 - Thrust washer
❑ For intermediate gear wheel.
❑ Renew.
❑ Note installation position ⇒ page 106 .
14 - Intermediate gear wheel
❑ Renew.
❑ A coating is applied to the new intermediate gear wheel which sets the correct tooth backlash through
wear.
Golf 2004 ➤ , Golf Plus 2005 ➤ , Passat 2006 ➤ , Touran 2003 ➤
4-cylinder diesel engine (2.0 l engine, 4 valve) - Edition 02.2011
104 Rep. gr.17 - Lubrication
