– Install insulation tray ⇒ General body repairs, exterior; Rep.
gr. 50 ; Body - front; Assembly overview - noise insulation .
– Carry out road test and read fault memories ⇒ Vehicle diag‐
nostic tester.
Specified torques
Threaded connection
Specified torque
Bolts, nuts M6 10 Nm
M8 20 Nm
M10 45 Nm
M12 60 Nm
1.4 Assembly mountings
Engine assembly mounting
A = 20 Nm + 90° (1/4 turn) further
1)
B = 40 Nm + 90° (1/4 turn) further
1)
C = 60 Nm + 90° (1/4 turn) further
1)
1)
Renew.
Gearbox assembly mounting
1 = 40 Nm + 90° (1/4 turn) further
1)
2 = 60 Nm + 90° (1/4 turn) further
1)
1)
Renew.
Pendulum support
A = 40 Nm + 90° (1/4 turn) further
1)
B = 100 Nm + 90° (1/4 turn) further
1)
1)
Renew.
Golf 2004 ➤ , Golf Plus 2005 ➤ , Passat 2006 ➤ , Touran 2003 ➤
4-cylinder diesel engine (2.0 l engine, 4 valve) - Edition 02.2011
14 Rep. gr.10 - Removing and installing engine
