30
7. INSERTING/REPLACING THE BATTERIES
1. The current battery capacity is displayed via the battery status display .
2. Switch off the meter before starting battery replacement.
3. Loosen the cross-head screw at the rear of the product with a small screwdriver.
4. Carefully remove the battery compartment lid.
5. If required, remove fl at batteries from the housing and insert three new batteries of the same
type (see technical data) into the battery compartment with the correct polarity.
6. Carefully replace the battery compartment lid on the meter and fasten it again with the
screw.
8. COMMISSIONING
After insertion of the batteries, you can start with the desired measuring process.
Push the button “MODE” for at least 2 seconds. The LC display lights up and the meter is
ready for operation.
To switch off the meter, push the button “MODE” again for at least 2 seconds.
To save energy, the current injection meter off automatically after being inactive for 3
minutes.
