VOLTCRAFT FM-400 - Control Elements

29
6. CONTROL ELEMENTS
1. Protective cap
2. Measuring prod
3. LC display
4. “SET” button
5. “CLR” button
6. On/off “MODE” button
7. Self-test adapter
8. Temperature and humidity sensor
9. Round plug
1. Battery display
2. Menu display
3. Test mode
4. Bar scale “MIN/MAX”
5. “DRY/MOIST/WET” indicator
6. Characteristic curve wood
7. Characteristic curve building
materials
8. Digital display for moisture in %
9. Bar scale for moisture measure-
ment
10. Digital display for temperature and
humidity
1
2
3
4
5
6
7
8
9
10
7
6
8
1
2
3
4
5
9
6
7
