The following functions are available:
Depending on the set battery type (LiPo, LiIo, LiFe, NiMH, NiCd, Pb), different setting functions are available.
For example, the setting function for the charge end voltage per cell is only available for lithium rechargeable
batteries.
Therefore, always set the rechargeable battery type rst and only then the other data, so that the charger can
offer the setting functions matching the rechargeable battery type.
Rechargeable battery type
For this, select the rechargeable battery type "LiPo", "LiIo", "LiFe", "NiMH", "NiCd" or "Pb".
As described above, this selection must be made rst, since the right setting functions matching the re-
chargeable battery type are only displayed then.
Battery Voltage
Depending on the set rechargeable battery type, the rechargeable battery voltage can be set here.
However, it is not possible to set any voltage, but the steps depend on the rated voltage of an individual cell
of the respective rechargeable battery type; see chapter 7.
For example, the rated voltage of a cell in LiPo rechargeable batteries is 3.7 V; the rechargeable battery volt-
age can thus only be set in steps of 3.7 V (3.7 V, 7.4 V, 11.1 V, etc.).
Charging current
Set the desired charging current here (0.1 - 7.0 A). It must be selected according to the rechargeable battery used.
Observe that the charging output of the charger is up to 50 W. Depending on the cell number, the maximum
charging current may therefore not be available.
Discharging current
Set the desired discharging current here (0.1 - 2.0 A). It must be selected according to the rechargeable battery
used.
Observe that the discharging output of the charger is max. 5 W. Depending on the cell number, the maximum
discharging current will therefore not be available.
BATT TYPE
LiPo
BATT VOLTS
7.4V(2S)
CHARGE CURRENT
2.2A
DSCH CURRENT
2.0A
To Next Page
